DER - Unit 2 - 100Mbps

The statistics were last updated Thursday, 9 August 2001 at 20:58 ,
at which time 'DERstack' had been up for 11 days, 13:47:41.
`Daily' Graph (5 Minute Average)
Max In: 88.8 kB/s (0.7%) Average In: 5805.0 B/s (0.0%) Current In: 435.0 B/s (0.0%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)
`Weekly' Graph (30 Minute Average)
Max In: 239.6 kB/s (1.9%) Average In: 3169.0 B/s (0.0%) Current In: 430.0 B/s (0.0%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)
`Monthly' Graph (2 Hour Average)
Max In: 416.1 kB/s (3.3%) Average In: 2733.0 B/s (0.0%) Current In: 13.4 kB/s (0.1%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)
`Yearly' Graph (1 Day Average)
Max In: 2177.0 kB/s (17.4%) Average In: 3003.0 B/s (0.0%) Current In: 3533.0 B/s (0.0%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)

GREEN ### Incoming Traffic in Bytes per Second
BLUE ### Outgoing Traffic in Bytes per Second
DARK GREEN### Maximal 5 Minute Incoming Traffic
MAGENTA### Maximal 5 Minute Outgoing Traffic
