DER - Unit 1 - 100Mbps

The statistics were last updated Thursday, 9 August 2001 at 20:58 ,
at which time 'DERstack' had been up for 11 days, 13:47:11.
`Daily' Graph (5 Minute Average)
Max In: 120.5 kB/s (1.0%) Average In: 6026.0 B/s (0.0%) Current In: 438.0 B/s (0.0%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)
`Weekly' Graph (30 Minute Average)
Max In: 342.4 kB/s (2.7%) Average In: 3334.0 B/s (0.0%) Current In: 428.0 B/s (0.0%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)
`Monthly' Graph (2 Hour Average)
Max In: 476.3 kB/s (3.8%) Average In: 2774.0 B/s (0.0%) Current In: 16.9 kB/s (0.1%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)
`Yearly' Graph (1 Day Average)
Max In: 2184.3 kB/s (17.5%) Average In: 3059.0 B/s (0.0%) Current In: 3533.0 B/s (0.0%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)

GREEN ### Incoming Traffic in Bytes per Second
BLUE ### Outgoing Traffic in Bytes per Second
DARK GREEN### Maximal 5 Minute Incoming Traffic
MAGENTA### Maximal 5 Minute Outgoing Traffic
