Pav. Anexo - Unit 1 - 100Mbps

The statistics were last updated Thursday, 9 August 2001 at 20:58 ,
at which time 'CIstack' had been up for 4:38:17.
`Daily' Graph (5 Minute Average)
Max In: 835.7 kB/s (6.7%) Average In: 20.3 kB/s (0.2%) Current In: 449.0 B/s (0.0%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)
`Weekly' Graph (30 Minute Average)
Max In: 989.1 kB/s (7.9%) Average In: 22.5 kB/s (0.2%) Current In: 443.0 B/s (0.0%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)
`Monthly' Graph (2 Hour Average)
Max In: 2201.6 kB/s (17.6%) Average In: 27.5 kB/s (0.2%) Current In: 55.8 kB/s (0.4%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)
`Yearly' Graph (1 Day Average)
Max In: 11.0 MB/s (88.1%) Average In: 25.5 kB/s (0.2%) Current In: 22.5 kB/s (0.2%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)

GREEN ### Incoming Traffic in Bytes per Second
BLUE ### Outgoing Traffic in Bytes per Second
DARK GREEN### Maximal 5 Minute Incoming Traffic
MAGENTA### Maximal 5 Minute Outgoing Traffic
