Pav. Anexo - Unit 1 - 100Mbps

The statistics were last updated Thursday, 9 August 2001 at 20:58 ,
at which time 'CIstack' had been up for 4:37:48.
`Daily' Graph (5 Minute Average)
Max In: 8326.4 kB/s (66.6%) Average In: 41.6 kB/s (0.3%) Current In: 457.0 B/s (0.0%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)
`Weekly' Graph (30 Minute Average)
Max In: 9732.6 kB/s (77.9%) Average In: 44.1 kB/s (0.4%) Current In: 443.0 B/s (0.0%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)
`Monthly' Graph (2 Hour Average)
Max In: 9732.6 kB/s (77.9%) Average In: 33.1 kB/s (0.3%) Current In: 55.8 kB/s (0.4%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)
`Yearly' Graph (1 Day Average)
Max In: 12.4 MB/s (98.8%) Average In: 27.9 kB/s (0.2%) Current In: 18.9 kB/s (0.2%)
Max Out: 0.0 B/s (0.0%) Average Out: 0.0 B/s (0.0%) Current Out: 0.0 B/s (0.0%)

GREEN ### Incoming Traffic in Bytes per Second
BLUE ### Outgoing Traffic in Bytes per Second
DARK GREEN### Maximal 5 Minute Incoming Traffic
MAGENTA### Maximal 5 Minute Outgoing Traffic
